Features
Supports 26-country keyboard layouts
Supports dynamic fuzzy decoding
Supports full ASCII data editing for online specified code systems
Supports Bluetooth-HID/SPP/BLE mode + 2.4G mode + wired USB mode
Technical Parameters
| Item |
Specification |
| Operating Current |
3.3V*60mA (Standby:0mA) |
| Working Time |
3 to 10 days |
| Charging Power |
5V-400mA |
| Communication Range |
Bluetooth ≤50m, 2.4G ≤100m |
| Storage |
16M, stores up to 8192 entries (≤250 characters per entry) |
| Light Source |
650nm Visible Laser |
| Scan Type |
Bidirectional Single-line Scanning |
| Decoding Precision |
≥3mil@PCS90% Code39 |
| Scan Width |
320mm |
| Decoding Speed |
400 scans/sec |
| Scan Angle |
Rotation ±30°, Pitch ±45°, Skew ±60° |
| Print Contrast |
≥20% |
| Anti-interference |
Not affected by factory lighting or sunlight |
| Depth of Field (250Lux) |
3mil: 5mm-180mm
10mil: 5mm-480mm
15mil: 30mm-650mm
30mil: 30mm-850mm |
| Decoding Set |
UPC/EAN, ISBN, ISSN, Code39, Code 39 Full ASCII, Code32, Code128, Code11, Code93, Codabar, Industrial 2 of 5, Interleaved 2 of 5, MSI, GS1 Data Bar, Febarban |
| Indication |
Buzzer, indicator LED |
| Trigger Mode |
Key trigger, auto-continuous |
| Button Lifespan |
1,000,000 presses |
| Laser Lifespan |
10,000 hours |
| Drop Test |
1.8 meters |
| Receiver / Wired Interface |
USB, USB Virtual COM Port |
Relevant Certifications
CE, FCC, RoHS
Environmental Parameters
| Item |
Specification |
| Operating Temperature |
-20°C to 50°C |
| Storage Temperature |
-20°C to 60°C |
| Relative Humidity |
5% - 95% (Non-condensing) |
Packing Specifications
| Item |
Specification |
| Quantity per Carton |
50pcs |
| Outer Carton Size |
53.54138cm |
| Net Weight / Carton |
14kg |
| Gross Weight / Carton |
15kg |
| Unit Dimension |
180 × 100 × 80mm |
| Unit Weight |
280g |
