Specifications
Supports 26-country keyboard layouts
Dynamic fuzzy decoding supported
Supports full ASCII data editing for custom codes
Technical Parameters
| Item |
Parameter |
| Operating Current |
3.3-5V*50mA (Standby:10mA) |
| Light Source |
650nm Visible Laser |
| Scan Type |
Bidirectional Single-line Scanning |
| Decoding Precision |
≥3mil@PCS90% Code39 |
| Scan Width |
320mm |
| Decoding Speed |
400 times/sec |
| Scan Angle |
Rotation ±30°, Pitch ±45°, Skew ±60° |
| Contrast |
≥20% |
| Anti-interference |
Not affected by factory lighting or sunlight |
| Depth of Field (250Lux) |
3mil: 5mm-180mm
10mil: 5mm-480mm
15mil: 30mm-650mm
30mil: 30mm-850mm |
| Decoding Set |
UPC/EAN, ISBN, ISSN, Code39, Code 39 Full ASCII, Code32, Code128, Code11, Code93, Codabar, Industrial 2 of 5, Interleaved 2 of 5, MSI, GS1 Data Bar, Febarban |
| Indication |
Buzzer & LED indicator |
| Trigger Mode |
Key trigger, Auto-continuous, Auto-sensing |
| Auto-sensing Interval |
0.3s |
| Button Lifespan |
500,000 presses |
| Laser Lifespan |
10,000 hours |
| Drop Test |
1.2 meters |
| Interface |
USB, USB Virtual COM, TTL, RS232 |
