| Technical Parameters |
Electrical Parameters: 3.3-5V×130mA (Standby: ≤90mA)
Lighting: 6500K LED
Aiming: 617nm LED
Sensor: 640×480 CMOS
Indication: Buzzer & LED indicator
Trigger Mode: Button trigger, Continuous mode, Auto-sensing
Decoding Precision: 1D ≥4mil, 2D ≥10mil
Scan Angle: Rotation ±360°, Pitch ±60°, Skew ±60°
Field of View: Horizontal 32°, Vertical 24°
Contrast: ≥20%
Max Anti-interference Illumination: 100,000Lux
Depth of Field (250Lux):
13mil-EAN13 (13 bytes) 30-220mm
4mil-Code39 (6 bytes) 60-100mm
15mil-QR (30 bytes) 30-200mm
10mil-PDF417 (30 bytes) 40-200mm
Decoding Capability:
1D: UPC, EAN, ISBN, ISSN, Code 128, Code 39, Code32, Code 93, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, IATA 2 of 5, MSI Plessey, Code 11, Codabar, GS1 Data Bar
2D: QR, Micro QR, Data Matrix, PDF417, MicroPDF417, Aztec, Maxi Code
LED Lifespan: 100,000 hours
Button Lifespan: 1,000,000 presses
Drop Test: 1.5 meters
Interface: USB, USB virtual serial port |
