Features
Supports 25-country keyboard layouts
Supports full ASCII data editing
Supports dynamic fuzzy decoding
Time system supported
Technical Parameters
| Item |
Specification |
| Operating Current |
3.3V*60mA (Standby: 0mA) |
| Communication Range |
Bluetooth ≤50m, 2.4G ≤100m |
| Storage |
16M, stores up to 8192 entries (≤128 characters per entry) |
| Working Time |
3 to 10 days |
| Charging Power |
5V-400mA |
| Light Source |
650nm Visible Laser |
| Scan Type |
Bidirectional Single-line Scanning |
| Decoding Precision |
≥3mil@PCS90% Code39 |
| Scan Width |
300mm |
| Decoding Speed |
300 times/sec |
| Print Contrast |
≥20% |
| Scan Angle |
Rotation ±30°, Pitch ±45°, Skew ±60° |
| Anti-interference |
Not affected by factory lighting or sunlight |
| Depth of Field |
3.3mil: 10mm-150mm
10mil: 10mm-300mm
15mil: 30mm-450mm
30mil: 30mm-650mm |
| Decoding Set |
UPC/EAN, ISBN, ISSN, Code39, Code 39 Full ASCII, Code32, Code128, Code11, Code93, Codabar, Industrial 2 of 5, Interleaved 2 of 5, MSI, GS1 Data Bar |
| Indication |
Buzzer, indicator LED |
| Trigger Mode |
Key trigger, auto-continuous |
| Button Lifespan |
500,000 presses |
| Laser Lifespan |
10,000 hours |
| Drop Test |
1 meter |
| Receiver / Wired Interface |
USB, USB Virtual COM Port |
