Features
Supports 25-country keyboard layouts
Supports full ASCII data editing
Contact pin short-circuit protection, contact status indicator light
Supports time system
Technical Parameters
| Item |
Specification |
| Electrical Parameters |
3.3V×190mA, (Standby: 0mA) |
| Working Time |
2 to 5 days |
| Charging Power |
5V-400mA |
| Communication Range |
≤100m |
| Storage |
4096 entries (≤500 characters per entry) |
| Illumination Light |
6500K LED |
| Aiming Light |
617nm LED |
| Sensor |
640×480 CMOS |
| Indication |
Buzzer, indicator LED |
| Trigger Mode |
Button trigger, continuous mode, auto-sensing |
| Decoding Precision |
≥4mil |
| Scan Angle |
Rotation ±360°, Pitch ±55°, Skew ±55° |
| Field of View |
Horizontal 34°, Vertical 26° |
| Print Contrast |
≥25% |
| Ambient Light Immunity |
Max 100000Lux |
| Depth of Field (250Lux) |
EAN13: 50-280mm (13mil)
Code39: 40-70mm (5mil 10 bytes)
QR: 40-200mm (20mil 16 bytes)
Data Matrix: 40-100mm (10mil 20 bytes)
PDF417: 30-100mm (6.67mil 7 bytes) |
| Decoding Capability |
1D: UPC, EAN, ISBN, ISSN, Code 128, Code 39, Code32, Code 93, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, IATA 2 of 5, MSI Plessey, Code 11, Codabar, GS1 Data Bar, GS1 Composite Plessey, Febarban
2D: QR, Micro QR, Data Matrix, PDF417, MicroPDF417, Aztec, Maxi Code, Hanxin |
| LED Lifespan |
100,000 hours |
| Button Lifespan |
1,000,000 presses |
| Drop Test |
1.8 meters |
| Cradle Interface |
USB, USB Virtual COM Port, Serial Port |
