| Features |
> Support multi-language keyboard
> Support full ASCII data editing
> Support invoice mode |
| Electrical Parameters |
3.3V × 190mA, Standby: 25mA |
| Illumination |
6500K LED |
| Aiming |
617nm LED |
| Sensor |
640×480 CMOS |
| Indication |
Buzzer & LED indicator |
| Trigger Mode |
Button, Continuous Mode, Auto-sensing |
| Resolution |
≥4mil |
| Scan Angle |
Rotation ±360°, Pitch ±55°, Skew ±55° |
| Field of View |
Horizontal 34°, Vertical 26° |
| Contrast |
≥25% |
| Ambient Light Immunity |
100,000Lux Max |
| Depth of Field (250Lux) |
EAN13: 50–280mm (13mil)
Code39: 40–70mm (5mil 10 characters)
QR: 40–200mm (20mil 16 characters)
Data Matrix: 40–100mm (10mil 20 characters)
PDF417: 30–100mm (6.67mil 7 characters) |
| Decoding Capability |
1D: UPC, EAN, ISBN, ISSN, Code 128, Code 39, Code32, Code 93, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, IATA 2 of 5, MSI Plessey, Code 11, Codabar, GS1 Data Bar, GS1 Composite, Plessey, Febraban
2D: QR, Micro QR, Data Matrix, PDF417, MicroPDF417, Aztec, Maxi Code, Hanxin |
| LED Lifespan |
100,000 hours |
| Button Lifespan |
500,000 presses |
| Drop Resistance |
1.2m |
| Interface |
USB, USB Virtual COM, TTL, Serial Port |
| Certifications |
CE, FCC, RoHS |
| Environmental Parameters |
Operating Temperature: -20℃ ~ 50℃
Storage Temperature: -40℃ ~ 70℃
Relative Humidity: 5%–95% (non-condensing) |
| Carton Spec |
50pcs per carton
Unit Size: 160 × 105 × 35mm
Outer Carton: 5434.519.5cm
USB Version:
Unit Weight: 170g
Net Weight / Carton: 8.5kg
Gross Weight / Carton: 9.5kg
RS232 Version:
Unit Weight: 240g
Net Weight / Carton: 12kg
Gross Weight / Carton: 13kg |
