Features
Supports 25-country keyboard layouts
Supports full ASCII data editing
Supports Bluetooth-HID/SPP/BLE mode + 2.4G mode + wired USB mode
Technical Parameters
| Item |
Specification |
| Electrical Parameters |
3.3V×150mA, (Standby: 0mA) |
| Working Time |
1 to 3 days |
| Charging Power |
5V-400mA |
| Communication Range |
Bluetooth ≤50m, 2.4G ≤100m |
| Storage |
3670 entries of EAN13 |
| Illumination Light |
6500K LED |
| Aiming Light |
617nm LED |
| Sensor |
640×480 CMOS |
| Indication |
Buzzer, indicator LED |
| Trigger Mode |
Button trigger, continuous mode, auto-sensing |
| Decoding Precision |
1D ≥4mil, 2D ≥10mil |
| Scan Angle |
Rotation ±360°, Pitch ±60°, Skew ±60° |
| Field of View |
Horizontal 32°, Vertical 24° |
| Print Contrast |
≥20% |
| Ambient Light Immunity |
Max 100000Lux |
| Depth of Field (250Lux) |
13mil-EAN13 (13 bytes): 30-220mm
4mil-Code39 (6 bytes): 60-100mm
15mil-QR (30 bytes): 30-200mm
10mil-PDF417 (30 bytes): 40-200mm |
| Decoding Capability |
1D: UPC, EAN, ISBN, ISSN, Code 128, Code 39, Code32, Code 93, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, IATA 2 of 5, MSI Plessey, Code 11, Codabar, GS1 Data Bar
2D: QR, Micro QR, Data Matrix, PDF417, MicroPDF417, Aztec, Maxi Code |
| LED Lifespan |
100,000 hours |
| Button Lifespan |
500,000 presses |
| Drop Test |
1.5 meters |
| Receiver / Wired Interface |
USB, USB Virtual COM Port |
